This float level gauge is used for all kind of oil tanks.
it’s good points simple installation and easy maintenance |
|
|
|
|
|
|
| DFLG - A(JIS F 7217A) |
|
DFLG - B(JIS F 7217B) |
|
DFLG - C(JIS F 7217C) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Model |
Mounting Type |
Nominaldia |
Application |
| DFLG-FCG-100 |
Direct acting |
100 |
Removable |
| DFLG-FCG-150 |
Direct acting |
150 |
Double bottom
(Lubricating oil,Water)tanks |
| DFLG-FCG-200 |
Direct acting |
200 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Model |
Cha-mber |
Float |
Sheave |
Spindle |
Flange |
Wire rope |
Sight glass |
| DFLG-A |
SGP |
SUS304 |
SS400 |
N/A |
SS400 |
SUS304 |
N/A |
| DFLG-B-150 |
SGP |
SUS304 |
SS400 |
N/A |
SS400 |
SUS304 |
N/A |
| DFLG-C-200 |
SGP |
SUS304 |
SS400 |
SUS304 |
SS400 |
N/A |
Hard |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Model |
Working condition |
Conn. size |
Chamber size |
Measuring renge at Sp.Gr 0.92 |
| Press |
Temp. |
| DFLG-A-100 |
3㎏/㎠ |
80°C |
5K 100A |
100A |
3000m/m |
| DFLG-B-150 |
3㎏/㎠ |
80°C |
5K 100A |
150A |
6000m/m |
| DFLG-C-200 |
3㎏/㎠ |
80°C |
5K 100A |
200A |
10000m/m |
|
| |
·The scale plate for above gauges are optional item
·The JIS F 7217 angle valve for DFLG-B is optional item. |
|
|
